HCT116 VIM RFP is a cell line exhibiting epithelial morphology that was isolated in 2018 from the rectum of a male patient with carcinoma colorectal. This cell line was deposited by MG Brattain and can be used in epithelial to mesenchymal transition (EMT), anti-EMT drug screening, colon cancer drug screening, vimentin intermediate filament dynamics research.
Product category
Human cells
Product type
Cell model
Reporter-labeled cell
Homo sapiens, human
Large intestine; Rectum
Carcinoma; Colorectal
3D cell culture
Assay development
Cancer research
Drug development
High-throughput screening
Product format
Storage conditions
Vapor phase of liquid nitrogen
Buy Now
Price: $5,008.00 ea
Discounts may be available for our fellow nonprofit organizations. Login to see your price.

Generally ships within 1-3 business days


ATCC determines the biosafety level of a material based on our risk assessment as guided by the current edition of Biosafety in Microbiological and Biomedical Laboratories (BMBL), U.S. Department of Health and Human Services. It is your responsibility to understand the hazards associated with the material per your organization’s policies and procedures as well as any other applicable regulations as enforced by your local or national agencies.

ATCC highly recommends that appropriate personal protective equipment is always used when handling vials. For cultures that require storage in liquid nitrogen, it is important to note that some vials may leak when submersed in liquid nitrogen and will slowly fill with liquid nitrogen. Upon thawing, the conversion of the liquid nitrogen back to its gas phase may result in the vial exploding or blowing off its cap with dangerous force creating flying debris. Unless necessary, ATCC recommends that these cultures be stored in the vapor phase of liquid nitrogen rather than submersed in liquid nitrogen.

Required Products

These products are vital for the proper use of this item and have been confirmed as effective in supporting functionality. If you use alternative products, the quality and effectiveness of the item may be affected.

Detailed product information


Specific applications
Epithelial to mesenchymal transition (EMT), anti-EMT drug screening, colon cancer drug screening, vimentin intermediate filament dynamics.


Cells per vial
Approximately 4.0 x 106
1.0 mL
Growth properties

The HCT116 VIM RFP reporter cell line, derived from the parental HCT116 (ATCC CCL-247™) colorectal carcinoma cell line, was created using CRISPR/Cas9 gene editing technology. The HCT116 VIM RFP reporter cell line carries a knock-in red fluorescent protein (RFP) reporter, which was integrated before the stop codon at the last exon of the endogenous vimentin (VIM) gene.

Epithelial to mesenchymal transition (EMT) has been recognized to play an important role in cancer cell metastasis and drug resistance. The EMT pathway is of increasing interest as a novel therapeutic avenue in the treatment of cancer. HCT116 VIM RFP cell line (ATCC CCL-247EMT™) was created using the CRISPR-Cas9 platform, in which a red fluorescent protein (RFP) reporter was integrated before the stop codon at the last exon of the endogenous vimentin gene, a widely used mesenchymal cell marker. The integrity of the VIM RFP knock-in allele has been verified at genomic, transcriptional, and translational levels. In HCT116 VIM RFP cells, vimentin-RFP expression can be robustly turned on in response to miR-200 family inhibitor treatment, as previously reported (Park et al, Genes Dev, 22: 894-907, 2008). In contrast, the expression of E-cadherin, a marker of epithelial cells, is significantly reduced upon miR-200 inhibitor treatment. In addition, hypomethylating agent 5-Aza-2’-Deoxycytidine treatment can induce an increase in VIM RFP expression effectively. The HCT116 VIM RFP cell line could be a useful in vitro cell model for dissecting the molecular switches underlying EMT and for identifying compounds that target EMT in colorectal cancer.

Handling information

Unpacking and storage instructions
  1. Check all containers for leakage or breakage.
  2. Remove the frozen cells from the dry ice packaging and immediately place the cells at a temperature below ­-130°C, preferably in liquid nitrogen vapor, until ready for use.
Complete medium
Base growth media for this cell line is McCoy’s 5A Medium (ATCC 30-2007). To make the complete medium add the following component to the base medium:

95% Air, 5% CO2
Handling procedure

To ensure the highest level of viability, thaw the vial and initiate the culture as soon as possible upon receipt. If upon arrival, continued storage of the frozen culture is necessary, it should be stored in liquid nitrogen vapor phase and not at -70°C.  Storage at -70°C will result in loss of viability.

  1. Thaw the vial by gentle agitation in a 37°C water bath. To reduce the possibility of contamination, keep the O-ring and cap out of the water.  Thawing should be rapid (approximately 2 minutes).
  2. Remove the vial from the water bath as soon as the contents are thawed, and decontaminate by dipping in or spraying with 70% ethanol. All of the operations from this point on should be carried out under strict aseptic conditions.
  3. Transfer the vial contents to a centrifuge tube containing  9.0 mL complete culture medium. and spin at approximately 125 x g for 5 to 7 minutes.
  4. Resuspend cell pellet with the recommended complete medium (see the specific batch information for the culture recommended dilution ratio). It is important to avoid excessive alkalinity of the medium during recovery of the cells.  It is suggested that, prior to the addition of the vial contents, the culture vessel containing the complete growth medium be placed into the incubator for at least 15 minutes to allow the medium to reach its normal pH (7.0 to 7.6). pH (7.0 to 7.6).
  5. Incubate the culture at 37°C in a suitable incubator.  A 5% CO2 in air atmosphere is recommended if using the medium described on this product sheet.


Subculturing procedure
Volumes used in this protocol are for 75 cm2 flask; proportionally reduce or increase amount of dissociation medium for culture vessels of other sizes. Corning® T-75 flasks (catalog #430641) are recommended for subculturing this product.
  1. Remove and discard culture medium.
  2. Briefly rinse the cell layer with 0.25% (w/v) Trypsin- 0.53 mM EDTA solution to remove all traces of serum that contains trypsin inhibitor.
  3. Add 2.0 to 3.0 mL of Trypsin-EDTA solution to flask and observe cells under an inverted microscope until cell layer is dispersed (usually within 5 to 15 minutes).
    Note: To avoid clumping do not agitate the cells by hitting or shaking the flask while waiting for the cells to detach. Cells that are difficult to detach may be placed at 37°C to facilitate dispersal.
  4. Add 6.0 to 8.0 mL of complete growth medium and aspirate cells by gently pipetting.
  5. Add appropriate aliquots of the cell suspension to new culture vessels.
    Cultures can be established between 2 x 104 and 4 x 104 viable cells/cm2.
  6. Incubate cultures at 37°C.
Interval: Maintain cultures at a cell concentration between 2 X 104 and 8 X 104 cell/cm2.
Subcultivation Ratio: A subcultivation ratio of 1:3 to 1:8 is recommended
Medium Renewal: 2 to 3 times per week
Reagents for cryopreservation
Complete growth medium supplemented with 5% (v/v) DMSO (ATCC 4-X)

Quality control specifications

Bacterial and fungal testing
Not detected
Mycoplasma contamination
Not detected
Virus testing
Cytomegalovirus (CMV): Not detected
Human papillomavirus (HPV): Not detected
Human Immunodeficiency virus (HIV): Not detected
Epstein-Barr virus (EBV): Not detected
Hepatitis B virus (HBV): Not detected
Functional tests
Genotype Testing for KI mutation: PCR – Band at 1127 kb corresponding to Vimentin-RFP LHA junction and band at 918 bp corresponding to RHA junction; Sanger Sequencing – confirms junction sequence
Population doubling time
Approximately 22 hrs
STR profiling
Amelogenin: x,y
CSF1PO: 7,10
D13S317: 10,13
D16S539: 11,13,14
D5S818: 10,11
D7S820: 11,12
TH01: 8,9
vWA: 20,22


The STR profile of the HCT-116 VIM RFP reporter cell line is approximately an 80% match to the parental HCT-116 cell line indicating that the cell lines are related (derived from common ancestry). The STR differences are likely attributed to microsatellite instability in the HT-116 cell line, which is a common feature of this cell line.1,2,3

  1. Ahmed DP, et al. Epigenetic and genetic features of 24 colon cancer cell lines. Oncogenesis Sep 16;2:e71. doi: 10.1038/oncsis.2013.35, 2013. PubMed: 34042735
  2. Gu C, et al. Inositol pyrophosphate profiling of two Hct116 cell lines uncovers variation in Insp8 levels. PLoS One 11(10):e0165286. doi: 10.1371/journal.pone.0165286, 2016. PubMed: 27788189
  3. Eshleman JR, et al. Increased mutation rate at the hprt locus accompanies microsatellite instability in colon cancer. Oncogene 10(1):33-7, 1995. PubMed: 7824277
Verification method
ATCC Cell Line Authentication Service
Functional Testing


MG Brattain
Year of origin

Legal disclaimers

Intended use
This product is intended for laboratory research use only. It is not intended for any animal or human therapeutic use, any human or animal consumption, or any diagnostic use.

The product is provided 'AS IS' and the viability of ATCC® products is warranted for 30 days from the date of shipment, provided that the customer has stored and handled the product according to the information included on the product information sheet, website, and Certificate of Analysis. For living cultures, ATCC lists the media formulation and reagents that have been found to be effective for the product. While other unspecified media and reagents may also produce satisfactory results, a change in the ATCC and/or depositor-recommended protocols may affect the recovery, growth, and/or function of the product. If an alternative medium formulation or reagent is used, the ATCC warranty for viability is no longer valid.  Except as expressly set forth herein, no other warranties of any kind are provided, express or implied, including, but not limited to, any implied warranties of merchantability, fitness for a particular purpose, manufacture according to cGMP standards, typicality, safety, accuracy, and/or noninfringement.


This product is intended for laboratory research use only. It is not intended for any animal or human therapeutic use, any human or animal consumption, or any diagnostic use. Any proposed commercial use is prohibited without a license from ATCC.

While ATCC uses reasonable efforts to include accurate and up-to-date information on this product sheet, ATCC makes no warranties or representations as to its accuracy. Citations from scientific literature and patents are provided for informational purposes only. ATCC does not warrant that such information has been confirmed to be accurate or complete and the customer bears the sole responsibility of confirming the accuracy and completeness of any such information.

This product is sent on the condition that the customer is responsible for and assumes all risk and responsibility in connection with the receipt, handling, storage, disposal, and use of the ATCC product including without limitation taking all appropriate safety and handling precautions to minimize health or environmental risk. As a condition of receiving the material, the customer agrees that any activity undertaken with the ATCC product and any progeny or modifications will be conducted in compliance with all applicable laws, regulations, and guidelines. This product is provided 'AS IS' with no representations or warranties whatsoever except as expressly set forth herein and in no event shall ATCC, its parents, subsidiaries, directors, officers, agents, employees, assigns, successors, and affiliates be liable for indirect, special, incidental, or consequential damages of any kind in connection with or arising out of the customer's use of the product. While reasonable effort is made to ensure authenticity and reliability of materials on deposit, ATCC is not liable for damages arising from the misidentification or misrepresentation of such materials.

Please see the material transfer agreement (MTA) for further details regarding the use of this product. The MTA is available at

Permits & Restrictions

Material Transfer Agreement Addendum for Screening Applications

For-profit organizations
For every order of this item, you must provide a signed Material Transfer Agreement Addendum for Screening Applications. We cannot ship this item until we receive this addendum. The person signing the addendum as the principal investigator must match the end user as listed on the applicable sales order for the item.

Email the signed addendum to [email protected] with a reference to both your account and sales order numbers. Once received, your addendum will be reviewed, and this item will be released for shipment if all requirements are met. Additional fees may apply if this product is being used for a screening use (ATCC ACS-2103F), and these fees will be applied after your order is confirmed. If you need assistance with your order, please contact our Customer Care team or your applicable distributor.

Import Permit for the State of Hawaii

If shipping to the U.S. state of Hawaii, you must provide either an import permit or documentation stating that an import permit is not required. We cannot ship this item until we receive this documentation. Contact the Hawaii Department of Agriculture (HDOA), Plant Industry Division, Plant Quarantine Branch to determine if an import permit is required.

This material is subject to the following restrictions in addition to those outlined in the ATCC Material Transfer Agreement:

  1. CRISPR Label License

For information on obtaining additional rights, please contact:

ATCC Licensing
Email: [email protected]

This material is subject to the following restrictions in addition to those outlined in the ATCC Material Transfer Agreement:

  1. CRISPR Label License, ERS Genomics

For information on obtaining additional rights, please contact:

ATCC Licensing
Email: [email protected]


Frequently Asked Questions


Curated Citations

Park SM, et al. The miR-200 family determines the epithelial phenotype of cancer cells by targeting the E-cadherin repressors ZEB1 and ZEB2. Genes Dev 22(7): 894-907, 2008. PubMed: 18381893

Schroy PC, et al. Detection of p21ras mutations in colorectal adenomas and carcinomas by enzyme-linked immunosorbent assay. Cancer 76: 201-209, 1995. PubMed: 8625092

Brattain MG, et al. Heterogeneity of malignant cells from a human colonic carcinoma. Cancer Res. 41: 1751-1756, 1981. PubMed: 7214343

Sun L, et al. Autocrine transforming growth factor-beta 1 and beta 2 expression is increased by cell crowding and quiescence in colon carcinoma cells. Exp. Cell Res. 214: 215-224, 1994. PubMed: 8082724

Santoro IM, Groden J. Alternative splicing of the APC gene and its association with terminal differentiation. Cancer Res. 57: 488-494, 1997. PubMed: 9012479
