Shox2

CRL-3256

Product category
Animal cells
Organism
Mus musculus, mouse
Cell type
embryonic stem cell, nodal cardiac myocyte-derived
Morphology
epithelial-like
Tissue
Heart; Sinoatrial node
Applications
3D cell culture
Product format
Frozen
Storage conditions
Vapor phase of liquid nitrogen
Buy Now
Price: $555.00 EA
Discounts may be available for our fellow nonprofit organizations. Login to see your price.

Generally ships within 1-3 business days

Documentation

ATCC determines the biosafety level of a material based on our risk assessment as guided by the current edition of Biosafety in Microbiological and Biomedical Laboratories (BMBL), U.S. Department of Health and Human Services. It is your responsibility to understand the hazards associated with the material per your organization’s policies and procedures as well as any other applicable regulations as enforced by your local or national agencies.

ATCC highly recommends that appropriate personal protective equipment is always used when handling vials. For cultures that require storage in liquid nitrogen, it is important to note that some vials may leak when submersed in liquid nitrogen and will slowly fill with liquid nitrogen. Upon thawing, the conversion of the liquid nitrogen back to its gas phase may result in the vial exploding or blowing off its cap with dangerous force creating flying debris. Unless necessary, ATCC recommends that these cultures be stored in the vapor phase of liquid nitrogen rather than submersed in liquid nitrogen.

Required Products

These products are vital for the proper use of this item and have been confirmed as effective in supporting functionality. If you use alternative products, the quality and effectiveness of the item may be affected.

Detailed product information

General

Specific applications
Can be used for the design of biological pacemakers, studying the biology and electrophysiology of sinoatrial nodal cells, and in animal models of cardiac pacemaker diseases such as AV block or sinus node dysfunction.

Characteristics

Volume
1.0 mL
Growth properties
Adherent
Derivation
Shox2 cell originated from the genetic selection of mouse ES cells using a 3.8 kb fragment of the Shox2 promoter.
Age
embryo
Gender
Male
Strain
129S1/SVmJ
Comments
Shox2 cells originated from the genetic selection of mouse ES cells using a 3.8 kb fragment of the Shox2 promoter. They exhibit a pacemaker-like molecular phenotype and gene expression profile including pacemaker-specific transcription factors (Tbx3  Tbx5 BMP4), structural proteins (alpha-cardiac actin; alpha-skeletal actin; desmin), connexins (Cx45; Cx30.2), ion channel subunits (Cav1.2; Cav1.3; Cav3.1), a sodium-calcium exchanger (NCX1) and a hyperpolarization activated cyclic nucleoside gated channel (HCN2).

Handling information

Unpacking and storage instructions
  1. Check all containers for leakage or breakage.
  2. Remove the frozen cells from the dry ice packaging and immediately place the cells at a temperature below ­-130°C, preferably in liquid nitrogen vapor, until ready for use.
Complete medium
The base medium for this cell line is Mouse ES Cell Basal Medium, Catalog No. SCRR-2011. To make the complete growth medium, add the following components to the base medium:
  • 2-mercaptoethanol to a final concentration of 0.05 mM
  • fetal bovine serum to a final concentration of 15%
Temperature
37°C
Atmosphere
95% Air, 5% CO2
Handling procedure
1 amp --> 1 T-75
Thaw ampoule in 37°C water bath for approximately 2 minutes.  Transfer thawed cell suspension to a 15.0 mL centrifuge tube containing 9mL complete medium.  Mix suspension by gentle inversion.  Remove 0.5-1.0 mL for cell count. Centrifuge remaining suspension in the 15 mL centrifuge tube at 175-195 x g (1000 rpm in an IEC HN SII centrifuge or equivalent) for 5 minutes, RT.  Discard supernatant and gently resuspended pellet in 5ml fresh complete medium.  Transfer 5 ml re-suspended cells into 1 T-75 flask containing 10 ml fresh medium. Place the cells in a 5% CO2 incubator @ 37°C
Subculturing procedure

Volumes used in this protocol are for 75 cm2 flasks; proportionally reduce or increase amount of dissociation medium for culture vessels of other sizes.

  1. Remove and discard culture medium. Briefly rinse the cell layer with Ca++/Mg++ free Dulbecco's phosphate-buffered saline (D-PBS) (ATCC 30-2200) or 0.25% (w/v) Trypsin - 0.53 mM EDTA (ATCC 30-2101) solution to remove all traces of serum which contains trypsin inhibitor.
  2. Add 2.0 to 3.0 ml of Trypsin-EDTA solution to flask and observe cells under an inverted microscope until cell layer is dispersed (usually within 5 to 15 minutes).

   Note: To avoid clumping do not agitate the cells by hitting or shaking the flask while waiting for the cells to detach. Cells that are difficult to detach may be placed at 37°C to facilitate dispersal.

  1. Add 2.0 to 3.0 ml of complete growth medium and aspirate cells by gently pipetting.
  2. Transfer cell suspension to a centrifuge tube and spin at approximately 125 xg for 5 to 10 minutes.
  3. Discard supernatant. Resuspend the cell pellet in fresh growth medium.
  4. Add appropriate aliquots of the cell suspension to new culture vessels.
  5. Incubate cultures at 37°C.



Subcultivation Ratio: 1:3 to 1:6 is recommended.

Medium Renewal: 2 to 3 times a week

Culture maintenance
Cultures are grown @ 37°C in a 95% air, 5% CO2 environment. Medium change every 2-4 days.
Reagents for cryopreservation
Fetal Bovine Serum supplemented with 5% (v/v) DSMO (ATCC 4-X)

History

Depositors
William Claycomb, Louisana State University
Year of origin
2012

Legal disclaimers

Intended use
This product is intended for laboratory research use only. It is not intended for any animal or human therapeutic use, any human or animal consumption, or any diagnostic use.
Warranty

The product is provided 'AS IS' and the viability of ATCC® products is warranted for 30 days from the date of shipment, provided that the customer has stored and handled the product according to the information included on the product information sheet, website, and Certificate of Analysis. For living cultures, ATCC lists the media formulation and reagents that have been found to be effective for the product. While other unspecified media and reagents may also produce satisfactory results, a change in the ATCC and/or depositor-recommended protocols may affect the recovery, growth, and/or function of the product. If an alternative medium formulation or reagent is used, the ATCC warranty for viability is no longer valid.  Except as expressly set forth herein, no other warranties of any kind are provided, express or implied, including, but not limited to, any implied warranties of merchantability, fitness for a particular purpose, manufacture according to cGMP standards, typicality, safety, accuracy, and/or noninfringement.

Disclaimers

This product is intended for laboratory research use only. It is not intended for any animal or human therapeutic use, any human or animal consumption, or any diagnostic use. Any proposed commercial use is prohibited without a license from ATCC.

While ATCC uses reasonable efforts to include accurate and up-to-date information on this product sheet, ATCC makes no warranties or representations as to its accuracy. Citations from scientific literature and patents are provided for informational purposes only. ATCC does not warrant that such information has been confirmed to be accurate or complete and the customer bears the sole responsibility of confirming the accuracy and completeness of any such information.

This product is sent on the condition that the customer is responsible for and assumes all risk and responsibility in connection with the receipt, handling, storage, disposal, and use of the ATCC product including without limitation taking all appropriate safety and handling precautions to minimize health or environmental risk. As a condition of receiving the material, the customer agrees that any activity undertaken with the ATCC product and any progeny or modifications will be conducted in compliance with all applicable laws, regulations, and guidelines. This product is provided 'AS IS' with no representations or warranties whatsoever except as expressly set forth herein and in no event shall ATCC, its parents, subsidiaries, directors, officers, agents, employees, assigns, successors, and affiliates be liable for indirect, special, incidental, or consequential damages of any kind in connection with or arising out of the customer's use of the product. While reasonable effort is made to ensure authenticity and reliability of materials on deposit, ATCC is not liable for damages arising from the misidentification or misrepresentation of such materials.

Please see the material transfer agreement (MTA) for further details regarding the use of this product. The MTA is available at www.atcc.org.

Permits & Restrictions

Import Permit for the State of Hawaii

If shipping to the U.S. state of Hawaii, you must provide either an import permit or documentation stating that an import permit is not required. We cannot ship this item until we receive this documentation. Contact the Hawaii Department of Agriculture (HDOA), Plant Industry Division, Plant Quarantine Branch to determine if an import permit is required.
